Important! This product is designed for and compatible with Galatea PCI Express Spartan 6 FPGA Development Board. This board is an IO breakout solution for Galatea PCI Express Spartan 6 FPGA Development Board. This product allows Galatea’s IOs to be broken out in to smaller 2×6 headers that would facilitate easy attachment of other peripheral expansion modules. The board features seven 2×6 expansion connector. Please note that the external power connector on Galatea PCI Express FPGA Development Board will not be accessible when this module is placed the high speed IO connector P5.
Features
| Title | Date | Download |
|---|---|---|
| User Manual | Feb 14 2018 | Download |
| Aug 22 2018 | Download | |
| Jan 21 2022 | Download | |
| Nov 10 2022 | Download |
Important! This product is designed for and compatible with Galatea PCI Express Spartan 6 FPGA Development Board. This board is an IO breakout solution for Galatea PCI Express Spartan 6 FPGA Development Board. This product allows Galatea’s IOs to be broken out in to smaller 2×6 headers that would facilitate easy attachment of other peripheral expansion modules. The board features seven 2×6 expansion connector. Please note that the external power connector on Galatea PCI Express FPGA Development Board will not be accessible when this module is placed the high speed IO connector P5.
Features
| Weight | 0.10 lbs |
|---|---|
| Dimensions | 5.00 x 3.00 x 2.00 in |
| Number of Expansion Connectors |
7 |
| Number of IOs (Max) |
56 |
| Onboard 1.5V to 3.3V Converter |
Yes (TXB0108) |
