This board is an IO breakout solution for Saturn Sparta6 development board. This product allows Saturn IOs to be broken out in to smaller 2×6 headers that would facilitate easy attachment of other peripheral expansion modules. The board features four 2×6 expansion connector. The traces are length matched. Please see the documentation for complete length matching details.
Features
| Title | Date | Download |
|---|---|---|
| User Manual | Feb 14 2018 | Download |
| Jan 21 2022 | Download | |
| Nov 10 2022 | Download |
This board is an IO breakout solution for Saturn Spartan 6 development board. This product allows Saturn IOs to be broken out in to smaller 2×6 headers that would facilitate easy attachment of other peripheral expansion modules. The board features four 2×6 expansion connector. The traces are length matched. Please see the documentation for complete length matching details.
Features
| Weight | 0.16 lbs |
|---|---|
| Dimensions | 5.00 x 3.00 x 2.00 in |
| IO Pairs Length Matched |
Yes |
